Bolt hrang hrang tan washer seal a ni.
Standard: DIN 470 a ni.
Commodity: Bolt hrang hrang tan washer seal a ni.
A hming pawh: Sealing Discs DIN 470 .
Thil hman tur: Carbon steel .
Diameter: 3, 4, 4, 6, 8, 10, 14, 16, 18, 22, 25, 28, (30), 32, (34), 36, 40, (42), 45, 50, 56, 0, 0, 0, 0, 56, 56, 56, 56, 56, 56, 125 a ni.
Finish: plain, black oxide, zinc plated, hot dipped galvanized, oxidation, dacromet, phosphating, cadmium electroplate, nickel plated
MOQ: 1000kgs a ni.
Lead time: Ni 30 atanga ni 60 thleng
Product Thuhmahruai .
Aya Fasteners (Hebei) Co., Ltd. hi China rama bolt siam nana sealing washer siamtu leh supplier zingah chuan a tawnhriat ngah ber pawl a ni a, a thil siam hi a hlawhtling hle a ni. Kan factory atang hian China rama bolt siamte tan sealing washer quality tha tak tak lei theih a ni. Price consultation atan min rawn biak theih reng e.
Khawvel puma customized fastening solutions supplier a nih angin AYA service process pawh hi AYA thil siam ang bawkin customer te nen a inhnaih hle a ni. Describing needs to follow-Up services, AYA chuan rang takin leh spare no effort to desping customers solve any fastening problems that lose, to elimining the concern of customers.
Product sawifiahna .
Product hming . | Bolt hrang hrang tan washer seal a ni. |
tih pawh a ni . | Sealing Discs DIN 470 . |
Bungrua | Carbon steel 1000 a ni. |
Nihphung pangngai | DIN 470 a ni. |
Diameter 100 a ni. | 3, 4, 5, 6, 8, 10, 12, 14, 16, 18, 20, 22, 25, 28, (30), 32, (34), 36, (38), 40, (42), 45, (48), 50, (52), 56, (60), 63, 80, 100, 125 |
Zo | Plain, black oxide, zinc plated, hot dipped galvanized, oxidation, dacromet, phosphating, cadmium electroplate, nickel plated |
Dimensions Table 1000 a ni.
| Nominal diameter 1000 a ni. d | 3 | 4 | 5 | 6 | 8 | 10 | 12 | 14 | 16 | |
| d | max a ni . | 3.03 | 4.0375 | 5.0375 | 6.0375 | 8.045 | 10.045 | 12.055 | 14.055 | 16.055 |
| min min ti a. | 2.97 | 3.9625 | 4.9625 | 5.9625 | 7.955 | 9.955 | 11.945 | 13.945 | 15.945 | |
| H | 1.2 | 1.34 | 1.35 | 1.67 | 1.94 | 2.67 | 2.77 | 2.94 | 3.11 | |
| SR 10 a ni. | 3 | 4 | 6 | 7 | 9 | 12 | 16 | 19 | 22 | |
| h | Nominal size a ni. | 0.8 | 0.8 | 0.8 | 1 | 1 | 1.6 | 1.6 | 1.6 | 1.6 |
| max a ni . | 0.95 | 0.95 | 0.95 | 1.15 | 1.15 | 1.75 | 1.75 | 1.75 | 1.75 | |
| min min ti a. | 0.65 | 0.65 | 0.65 | 0.85 | 0.85 | 1.45 | 1.45 | 1.45 | 1.45 | |
| unit 1000 ah≈kg a ni. | ≈ | 0.047 | 0.084 | 0.132 | 0.236 | 0.517 | 1.05 | 1.49 | 2.02 | 2.63 |
| Nominal diameter 1000 a ni. d | 18 | 20 | 22 | 25 | 28 | -30 | 32 | -34 | 36 | |
| d | max a ni . | 18.055 | 20.065 | 22.065 | 25.065 | 28.065 | 30.065 | 32.08 | 34.08 | 36.08 |
| min min ti a. | 17.945 | 19.935 | 21.935 | 24.935 | 27.935 | 29.935 | 31.92 | 33.92 | 35.92 | |
| H | 3.28 | 3.45 | 4.09 | 4.38 | 4.53 | 4.77 | 4.95 | 5.11 | 5.36 | |
| SR 10 a ni. | 25 | 28 | 30 | 34 | 40 | 42 | 45 | 48 | 50 | |
| h | Nominal size a ni. | 1.6 | 1.6 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| max a ni . | 1.75 | 1.75 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | |
| min min ti a. | 1.45 | 1.45 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | |
| unit 1000 ah≈kg a ni. | ≈ | 3.35 | 4.12 | 7.1 | 8.98 | 11.1 | 12.6 | 13.2 | 14.8 | 16.7 |
| Nominal diameter 1000 a ni. d | -38 | 40 | -42 | 45 | -48 | 50 | -52 | 56 | -60 | |
| d | max a ni . | 38.08 | 40.08 | 42.08 | 45.08 | 48.08 | 50.08 | 52.095 | 56.095 | 60.095 |
| min min ti a. | 37.92 | 39.92 | 41.92 | 44.92 | 47.92 | 49.92 | 51.905 | 55.905 | 59.905 | |
| H | 5.6 | 5.7 | 5.8 | 6.15 | 6.38 | 6.62 | 6.66 | 7.06 | 7.47 | |
| SR 10 a ni. | 52 | 56 | 60 | 63 | 68 | 70 | 75 | 80 | 85 | |
| h | Nominal size a ni. | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 2 |
| max a ni . | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | 2.15 | |
| min min ti a. | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | 1.85 | |
| unit 1000 ah≈kg a ni. | ≈ | 19.7 | 20.5 | 22.6 | 26.1 | 29.5 | 32.1 | 34.5 | 40.2 | 46.3 |
| Nominal diameter 1000 a ni. d | 63 | 80 | 100 | 125 | - | - | - | - | - | |
| d | max a ni . | 63.095 | 80.095 | 100.11 | 125.125 | - | - | - | - | - |
| min min ti a. | 62.905 | 79.905 | 99.89 | 124.875 | - | - | - | - | - | |
| H | 7.7 | 10.41 | 12.23 | 14.2 | - | - | - | - | - | |
| SR 10 a ni. | 90 | 112 | 140 | 180 | - | - | - | - | - | |
| h | Nominal size a ni. | 2 | 3 | 3 | 3 | - | - | - | - | - |
| max a ni . | 2.15 | 3.15 | 3.15 | 3.15 | - | - | - | - | - | |
| min min ti a. | 1.85 | 2.85 | 2.85 | 2.85 | - | - | - | - | - | |
| unit 1000 ah≈kg a ni. | ≈ | 50.9 | 134 | 204 | 313 | - | - | - | - | - |
Product details .
Product a thatna te .
Bolt tan washer sealing a thatna .
1. Sealing washers te hian bolt an neih avangin vibration resistance an nei tha hle.
2. Sealing discs DIN 470 hian a rualin sealing leh locking a nei thei a.
3. Sealing washer hian one-piece construction a nei a.
4. High-Material quality tha tak tak, leh washers te service life rei tak.
5. A pum puia-Process Tracking Quality Monitoring hian sealing washers bulk quality a tichiang a ni.
6. Aya hian fastener field-ah experience hautak tak a nei a.
Quality inspection .
Internal process audition hi siam chhuah a ni fo thin a, chu chuan a siam dan a that leh that loh a enfiah thin.
Quality guarantee leh testing chungchangah hian fastener siamna atana thil pawimawh tak a ni. AYA-ah chuan quantitative analysis method hmanga fastener thlirletna atan inspection kimchang ber an nei thin. A tawpah chuan result report kimchang tak pawh hian quality chu a tichiang hle ang.
Packaging & Container loading .
Aya hian a lan dan tihchangtlunna tur leh thawn chhuahna kawngah pawh a chhe thei lo tur atan packaging-a R&D chu a ngai pawimawh hle a ni.
100% on-Time delivery guarantee a ni.
Hman dan tur scenario .
Engvangin nge Aya hi kan thlan?
AYA hian kum tin khawvel hmun hrang hrang atanga 1000+ member te tan exclusive services a pe thin a, chain service solution system danglam tak neiin, exclusive fastening solution i hmuh theih nan mouse i click mai a ngai a, door-door services te chu i hmang thei ang.
