In / thil siam chhuah . / Screws te chu . / Self tapping screw te pawh a awm bawk. / Lungawi

thil siam chhuah .

Truss tapping screw 1000 a ni.

Standard: ASME B 18.6.4
Thread chi hrang hrang: Mahni self-Thread tapping .
Commodity: truss tapping screw .
A hming pawh: Truss Head Self Tapping Screws
Thil hman tur: Carbon steel .
Form/shape a tip: Type AB .
A chhuahna tur hmun hi a la awm lo.
Finish: plain, black oxide, zinc plated, thick-film passivated(zsml), zinc flake, silver(zfshl), hot dipped galvanized, organic, geomet, dacromet, phosphating, cadmium electroplate, nickel plated
A rilru a hah lutuk chuan a rilru a buai em em a, a rilru a hah lutuk chuan a rilru a buai em em bawk a. ISO
Lu chi hrang hrang: Truss lu .
Drive chi hrang hrang: A chhunga slot .
MOQ: 1000kgs a ni.
Lead time: Ni 30 atanga ni 60 thleng

Inquiry thawn rawh .

Product Thuhmahruai .

Aya Fasteners (Hebei) Co., Ltd. hi China rama truss tapping screw siamtu leh supplier zingah chuan a tawnhriat ngah ber pawl a ni. Kan factory atang hian China rama siam truss tapping screw quality tha tak tak truss tapping screw lei theih a ni. Price consultation atan min rawn biak theih reng e.

Self Tapping Screws-AYA

Khawvel puma customized fastening solutions supplier a nih angin AYA service process pawh hi AYA thil siam ang bawkin customer te nen a inhnaih hle a ni. Describing needs to follow-Up services, AYA chuan rang takin leh spare no effort to desping customers solve any fastening problems that lose, to elimining the concern of customers.

Product sawifiahna .

Product hming .	Truss tapping screw 1000 a ni.
tih pawh a ni .	Truss Head Self Tapping Screws .
Bungrua	Carbon steel 1000 a ni.
Nihphung pangngai	ASME B 18.6.4 a ni.
Form/shape a tip .	Type AB 1000 a ni.
Diameter 100 a ni.	0#,1#,2#,3#,4#,5#,6#,7#,8#,10#,12#,1/4,5/16
Zo	Plain, black oxide, zinc plated, hot dipped galvanized, oxidation, dacromet, phosphating, cadmium electroplate, nickel plated
lu chi hrang hrang .	Truss lu a ni .
Drive chi hrang hrang .	A chhung lam slot .
Thread chi hrang hrang .	Mahni self-Screw thread-a tap a ni.
A danglamna tur tehfung siam .	A rilru a hah lutuk chuan a rilru a buai em em a, a rilru a hah lutuk chuan a rilru a buai em em bawk a. ISO

Dimensions Table 1000 a ni.

Truss Tapping Screw 2D

Nominal diameter 1000 a ni. d		0#	1#	2#	3#	4#	5#	6#	7#	8#	10#	12#	1/4	5/16
d	Nominal size a ni.	0.06	0.073	0.086	0.099	0.112	0.125	0.138	0.151	0.164	0.19	0.216	0.25	0.3125
dk	max a ni .	0.131	0.164	0.194	0.226	0.257	0.289	0.321	0.352	0.384	0.448	0.511	0.573	0.698
dk	min min ti a.	0.119	0.149	0.18	0.211	0.241	0.272	0.303	0.333	0.364	0.425	0.487	0.546	0.666
k	max a ni .	0.037	0.045	0.053	0.061	0.069	0.078	0.086	0.094	0.102	0.118	0.134	0.15	0.183
k	min min ti a.	0.029	0.037	0.044	0.051	0.059	0.066	0.074	0.081	0.088	0.103	0.118	0.133	0.162
R	max a ni .	0.087	0.107	0.129	0.151	0.169	0.191	0.211	0.231	0.254	0.283	0.336	0.375	0.457
n	max a ni .	0.023	0.026	0.031	0.035	0.039	0.043	0.048	0.048	0.054	0.06	0.067	0.075	0.084
n	min min ti a.	0.016	0.019	0.023	0.027	0.031	0.035	0.039	0.039	0.045	0.05	0.056	0.064	0.072
t	max a ni .	0.022	0.027	0.031	0.036	0.04	0.045	0.05	0.054	0.058	0.068	0.077	0.087	0.106
t	min min ti a.	0.014	0.018	0.022	0.026	0.03	0.034	0.037	0.041	0.045	0.053	0.061	0.07	0.085

Product details .

Truss Tapping Screw details

Product a thatna te .

Truss Tapping Screw advantage

Truss tapping screw a thatna te

1. Truss tapping screw hi connection mamawhna atan environment hrang hrangah hman a ni nasa hle.

2. Self-tapping approach hmang hian hnathawh dan thianghlim humhim turin mess a siam tlem zawk tak zet ang.

3. Structure bik hian holding theihna ropui tak a pe a.

4. AYA Thil siamchhuahna step tinte chu a bul atanga a tawp thlengin enfiah thin ang che. Top quality chuan completion item requirements a tihlawhtling ngei ang.

5. Framework bik hian fasten a awlsam phah.

6. AYA chuan kan customer ten an local market-a pricing advantage an siam theih nan item expense tihsan nan a senso tihsan tumin hma a la zel a.

Quality inspection .

Quality Check-AYA Fasteners

Packaging & Container loading .

Packing-AYA Fasteners

Hman dan tur scenario .

Usage-AYA Fasteners

Engvangin nge Aya hi kan thlan?

AYA hian kum tin khawvel hmun hrang hrang atanga 1000+ member te tan exclusive services a pe thin a, chain service solution system danglam tak neiin, exclusive fastening solution i hmuh theih nan mouse i click mai a ngai a, door-door services te chu i hmang thei ang.
