In / thil siam chhuah . / Screws te chu . / Self tapping screw te pawh a awm bawk. / Lungawi

thil siam chhuah .

A lu flat concrete screw a awm bawk.

Standard: ASME B 18.6.4
Thread chi hrang hrang: Mahni self-Screw thread tapping .
Commodity: A lu chu flat lu concrete screw a ni.
A hming pawh: Self CounterSunk Screws
Thil hman tur: carbons steel .
A chhuahna tur hmun hi a la awm lo.
Finish: plain, black oxide, zinc plated, hot dipped galvanized, oxidation, dacromet, phosphating, cadmium electroplate, nickel plated
Lu chi hrang hrang: Countersunk lu / lu flat .
Drive chi hrang hrang: A chhunga slot .
A rilru a hah lutuk chuan a rilru a buai em em a, a rilru a hah lutuk chuan a rilru a buai em em bawk a. ISO 1482, JIS B 1115 (f)
MOQ: 1000kgs a ni.
Lead time: Ni 30 atanga ni 60 thleng

Inquiry thawn rawh .

Product Thuhmahruai .

Aya Fasteners (Hebei) Co., Ltd. hi China rama flat head concrete screw siamtu leh supplier zingah chuan a tawnhriat ngah ber pawl a ni a. Kan factory atang hian China rama siam flat head concrete screw quality tha tak tak flat head concrete screw lei theih a ni. Price consultation atan min rawn biak theih reng e.

Flat Head Concrete Screws-ASME B 18.6.4-AYA

Khawvel puma customized fastening solutions supplier a nih angin Aya-a Senvice process pawh hi AYA thil siam ang bawkin customer te nen a inhnaih hle a ni. Describing needs to follow-Up services, AYA chuan rang takin leh spare no effort to desping customers solve any fastening problems that lose, to elimining the concern of customers.

Product sawifiahna .

Product hming .	A lu flat concrete screw a awm bawk.
tih pawh a ni .	Self countersunk screw te pawh a awm bawk.
Bungrua	Carbon steel 1000 a ni.
Nihphung pangngai	ASME B 18.6.4 a ni.
A danglamna tur tehfung siam .	Asme B 18.6.5M,iso 1482,Jis B 1115 (f)
Diameter 100 a ni.	0#,1#,2#,3#,4#,5#,6#,7#,8#,10#,12#,1/4,5/16
Zo	Plain, black oxide, zinc plated, hot dipped galvanized, oxidation, dacromet, phosphating, cadmium electroplate, nickel plated
lu chi hrang hrang .	Countersunk lu / lu flat tak tak .
Drive chi hrang hrang .	A chhung lam slot .
Thread chi hrang hrang .	Mahni self-Screw thread-a tap a ni.

Dimensions Table 1000 a ni.

Flat Head Concrete Screws-ASME B 18.6.4-2D

Nominal diameter 1000 a ni. d		0#	1#	2#	3#	4#	5#	6#	7#	8#	10#	12#	1/4	5/16
d	Nominal size a ni.	0.0600	0.0730	0.0860	0.0990	0.1120	0.1250	0.1380	0.1510	0.1640	0.1900	0.2160	0.2500	0.3125
L	min min ti a.	3/16	3/16	3/16	7/32	1/4	1/4	5/16	3/8	7/16	1/2	9/16	5/8	13/16
dk	max a ni .	0.112	0.137	0.162	0.187	0.212	0.237	0.262	0.287	0.312	0.362	0.412	0.477	0.597
dk	min min ti a.	0.096	0.120	0.144	0.167	0.191	0.215	0.238	0.262	0.285	0.333	0.380	0.442	0.556
k	Ref.	0.035	0.043	0.051	0.059	0.067	0.075	0.083	0.091	0.100	0.116	0.132	0.153	0.191
n	max a ni .	0.023	0.026	0.031	0.035	0.039	0.043	0.048	0.048	0.054	0.060	0.067	0.075	0.084
n	min min ti a.	0.016	0.019	0.023	0.027	0.031	0.035	0.039	0.039	0.045	0.050	0.056	0.064	0.072
t	max a ni .	0.015	0.019	0.023	0.027	0.030	0.034	0.038	0.041	0.045	0.053	0.060	0.070	0.088
t	min min ti a.	0.010	0.012	0.015	0.017	0.020	0.022	0.024	0.027	0.029	0.034	0.039	0.046	0.058

Product details .

Flat Head Concrete Screws-ASME B 18.6.4-detail

Product a thatna te .

Flat Head Concrete Screws-ASME B 18.6.4-advanatage

A thatna te .

1. Flathead concrete screw hi basic construction-a anchor temporary atan a tha hle a, lakchhuah a awlsam bawk.

2. Flat head hi a hman awlsam a, a hman dan tur chu a hman dan bulpui ber nen a ni.

3. Concrete grounds chu bending lovin a lut thei.

4. High-standard materials hian quality tha tak a siam a, physical performance tha tak a nei bawk.

5. Aya hi global fastener siamtu tha ber nihna atan a inpe fo thin.

6. AYA hian fastener zawng zawng hi ISO9001 hmangin strict takin a siam chhuak thin.

Quality inspection .

Flat Head Concrete Screws-ASME B 18.6.4-check

Production-a link awm apiang chu quality control personnel-te'n an enkawl ang a, chu chuan final product chu customer beisei ang a nih theih nan a pui ang.

Testing instrument thiam tak tak leh quality control personnel tawnhriat ngah tak takte chuan customer te hnenah quality inspection report dik zawk an pe thei a ni.

Packaging & Container loading .

Flat Head Concrete Screws-ASME B 18.6.4-package

Aya product packaging hian product laka venhimna tha tak a pe thei mai bakah, a product mawina pawh a ti tha thei hle.

Aya hian custom labeling service a pe thin.

Hman dan tur scenario .

Flat Head Concrete Screws-ASME B 18.6.4-usage

Engvangin nge Aya hi kan thlan?

AYA-advantage

AYA hian kum tin khawvel hmun hrang hrang atanga 1000+ member te tan exclusive services a pe thin a, chain service solution system danglam tak neiin, exclusive fastening solution i hmuh theih nan mouse i click mai a ngai a, door-door services te chu i hmang thei ang.
